Nippe Centerless Grinding Blades
Nippe Grinders Infeed Blades
| Wheel Width & Type | Carbide Tip | Work Diameter Range | LENGTH “A” | HEIGHT “B” | BODY “C” | POCKET “D” | TIP WIDTH “E” | STANDARD CARBIDE WIDTH “F” |
| 8.25″ INFEED | 3-230240 | 1/16″ – 1/8″ | 12.532″ | 3.985″ | .407″ | 8.670″ | 3/64″ | 3/64″ |
| 3-230241 | 1/8″ – 1/4″ | 12.532″ | 3.922″ | .407″ | 8.670″ | 3/32″ | 3/32″ | |
| 3-230242 | 1/4″ – 5/16″ | 12.532″ | 3.922″ | .469″ | 8.670″ | 5/32″ | 3/16″ | |
| 3-230243 | 5/16″ – 15/32″ | 12.532″ | 3.922″ | .469″ | 8.670″ | 1/4″ | 1/4″ | |
| 3-230244 | 15/32″ – 23/32″ | 12.532″ | 3.922″ | .469″ | 8.670″ | 5/16″ | 5/16″ | |
| 3-230245 | 23/32″ – 1 3/16″ | 12.532″ | 3.922″ | 15/32″ | .469″ | 1/2″ | ||
| 3-230246 | 1 3/16″ – 3 9/16″ | 12.532″ | 3.313″ | .469″ | 15/32″ | 1/2″ |
Nippe Grinders Thrufeed Blades
| Wheel Width & Type | Carbide Tip | Work Diameter Range | LENGTH “A” | HEIGHT “B” | BODY “C” | POCKET “D” | TIP WIDTH “E” | STANDARD CARBIDE WIDTH “F” |
| 8.25″ THRUFEED | 3-230237 | 1/16″ – 1/8″ | 16.545″ | 3.985″ | .407″ | 8.670″ | 3/64″ | 3/64″ |
| 3-230231A | 1/8″ – 1/4″ | 16.545″ | 3.985″ | .407″ | 8.670″ | 3/32″ | 3/32″ | |
| 3-230231 | 1/8″ – 1/4″ | 16.545″ | 3.985″ | .407″ | 8.670″ | 3/32″ | 3/32″ | |
| 3-230232 | 1/4″ – 5/16″ | 16.545″ | 3.985″ | .469″ | 8.670″ | 5/32″ | 3/16″ | |
| 3-230233 | 5/16″ – 15/32″ | 16.545″ | 3.985″ | .4692″ | 8.670″ | 1/4″ | 1/4″ | |
| 3-230234 | 15/32″ – 23/32″ | 16.545″ | 3.938″ | .469″ | 8.670″ | 5/16″ | 5/16″ | |
| 3-230235 | 23/32″ – 1 3/16″ | 16.545″ | 3.938″ | .469″ | 15/32″ | 1/2″ | ||
| 3-230236 | 1 3/16″ – 3 9/16″ | 16.545″ | 3.422″ | .469″ | 15/32″ | 1/2″ |
